The Newman's Energy Machine

The current flow measurements

created on 12-14-98 - JLN Labs - last update on 12-14-98

This analog voltmeter has been connected accross a 1k carbon resistor in series with the power supply output, this shows the current flow output from the power supply. The diagram above shows the current measurement with the digital multimeter.

This analog voltmeter has been connected accross a 1k carbon resistor in series with the Newman's Coil, this shows the current flow through the coil. The diagram above shows the current measurement with the digital multimeter.
During these two measurements the two current 1k probe resistors has been let connected during all the test for avoiding some impedance modifications in the circuit.
