The Motionless Electromagnetic Generator,
Extracting Energy from a Permanent Magnet with Energy-Replenishing from the Active Vacuum

from Thomas E. Bearden, Ph.D. James C. Hayes, Ph.D. James L. Kenny, Ph.D. Kenneth D. Moore, B.S. Stephen L. Patrick, B.S.

"..This one works beautifully and produces COP=5.0..." has said Tom Bearden

Created on 10-06-00 - JLN Labs - Last update 05-10-02

All informations in this page are published free and are intended for private/educational purposes and not for commercial applications

The MEG diagrams published in these pages are currently under test by JL Naudin and may be subject to modifications after that they have been published on this site. They are the result of some attempts of a private and fully independant replication by the author. These diagrams are not the original MEG diagrams being tested by the Bearden's teamwork or some accredited labs.

Disclaimer: The author assumes no liability for any incidental, consequential or other liability from the use of this information. All risks and damages, incidental or otherwise, arising from the use or misuse of the information contained herein are entirely the responsibility of the user. Although careful precaution has been taken in the preparation of this material, I assume no responsibility for omissions or errors in the diagrams or measurement datas published here.

United States Patent 6,362,718
Patrick ,   et al. March 26, 2002

US Patent 6,362,718 : Motionless Electromagnetic Generator
See the full MEG patent with diagrams ( 15 pages )
Abstract

An electromagnetic generator without moving parts includes a permanent magnet and a magnetic core including first and second magnetic paths. A first input coil and a first output coil extend around portions of the first magnetic path, while a second input coil and a second output coil extend around portions of the second magnetic path. The input coils are alternatively pulsed to provide induced current pulses in the output coils. Driving electrical current through each of the input coils reduces a level of flux from the permanent magnet within the magnet path around which the input coil extends. In an alternative embodiment of an electromagnetic generator, the magnetic core includes annular spaced-apart plates, with posts and permanent magnets extending in an alternating fashion between the plates. An output coil extends around each of these posts. Input coils extending around portions of the plates are pulsed to cause the induction of current within the output coils.

Inventors: Patrick Stephen L; Bearden Thomas E.; Hayes James C.; Moore Kenneth D.; Kenny James L.
Appl. No.: 656313
Filed: September 6, 2000
4 July, 2001 : Message from Tom Bearden ( Circulate Widely )

This review by Myron Evans is fantastic, and it places EM energy from the vacuum very solidly into the literature. It will be published in the forthcoming three volumes of M.W. Evans, ed., Modern Nonlinear Optics, Second Edition, Wiley, 2001.

I have the permission of Myron Evans to post the paper until the publication of the book toward the end of this year.

Cheers,

Tom Bearden

The Link Between the Sachs and O(3) Theories of Electrodynamics by M.W. Evans ( PDF document 409 Kb )
Website address:
http://www.cheniere.org/references/index.html


Foundations of Physics Letters, Vol. 14., No. 1, 2001

EXPLANATION OF THE MOTIONLESS ELECTROMAGNETIC GENERATOR WITH 0(3) ELECTRODYNAMICS

P. K. Anastasovski,  T. E. Bearden,  C. Ciubotariu,  W. T. Coffey,  L. B. Crowell,  G. J. Evans,  M. W. Evans,  R. Flower, A. Labounsky,  B. Lehnert,  M. Mészáros,  P. R. Molnar,  J. K. Moscicki,  S. Roy, and J.P. Vigier.

Institute for Advanced Study, Alpha Foundation - Institute of Physics, 11 Rutafa Street, Building H - Budapest, H-1165, Hungary


The MEG paper : Extracting Energy from a Permanent Magnet with Energy-Replenishing from the Active Vacuum, a PDF document ( 69 pages 1,29 MB), by T.E. Bearden

MEG patent status, manufacturing update.  Literature update. October 30, 2001

Interesting papers and documents about the project :

Link to the main Tom Bearden Web site : http://www.cheniere.org/

The Worldwide MEG replications (03-29-02)

Interesting patents to explore which have some similarities or interesting characteristics :

METHODS FOR CONTROLLING THE PATH OF MAGNETIC FLUX FROM A PERMANENT MAGNET AND DEVICES INCORPORATING THE SAME

http://l2.espacenet.com/dips/viewer?PN=WO0007285&CY=ep&LG=en&DB=EPD

Patent Number: WO0007285
Publication date: 2000-02-10
Inventor(s): FLYNN CHARLES J
Applicant(s):: MAGNETIC REVOLUTIONS LIMITED L (US)

Abstract : A permanent magnet device (110) includes a permanent magnet (112) having North and South pole faces with a first pole piece (114) positioned adjacent one pole face thereof and a second pole piece (116) positioned adjacent the other pole face thereof so as to create at least two potential magnetic flux paths (130, 132). First control coils (122, 124) are positioned along one flux path (130) and second control coils (126, 128) is positioned along the other flux path (132), each coil being connected to a control circuit (not shown) for controlling the energization thereof. The control coils (122, 124, 126, 128) may be energized in a variety of ways to achieve desirable motive and static devices, including linear reciprocating devices, linear motion devices, rotary motion devices and power conversion.

Link to the Flynn's web site : About the Flynn's Parallel Path Technology

January 20th, 2001 : Interesting papers and patents :


Email : JNaudin509@aol.com
